Description
The MPT MDP1303 is a compact 350 W bench drill press for accurate, repeatable drilling in metal, wood and plastic. It has a 13 mm (1/2″) chuck, 50 mm of spindle travel and five speed settings from 620 to 2620 r/min, so you can match the speed to the material and bit size. The motor is wound with 100% copper wire, and the cast iron base keeps the machine steady while you drill.
Key Features
- 100% copper wire motor: a longer-lasting motor.
- Cast iron base: stable and low in vibration for more accurate holes.
- 5 speed settings (620 to 2620 r/min): suits different materials and drill sizes.
- 13 mm (1/2″) max drilling diameter: handles common drilling jobs in the workshop.
- Precise production technology: built for accurate drilling.
- Compact size: a 300 × 195 mm base fits a normal workbench.
- 220 to 240 V, 50/60 Hz: works on a standard supply at either frequency.
Specifications
| Specification | Details |
|---|---|
| Item No. | MDP1303 |
| Product Name | Drill Press |
| Rated Voltage | 220-240 V ~ 50/60 Hz |
| Motor Power | 350 W |
| Max Drilling Diameter | 13 mm (1/2″) |
| Chuck Capacity | 1.5-13 mm |
| Spindle Travel | 50 mm |
| Speed Settings | 5 |
| No-load Speed | 620-2620 r/min |
| Spindle Taper | B16 |
| Max Distance, Spindle Axis to Column | 105 mm |
| Max Distance, Spindle Axis to Table | 220 mm |
| Max Distance, Spindle Axis to Base | 300 mm |
| Swing | 210 mm |
| Table Size | 160 × 160 mm |
| Base Size | 300 × 195 mm |
| Column Diameter | 46 mm |
| Height | 580 mm |
| Net / Gross Weight | 16 / 17 kg |
